Square D NQ42L2C14 Panelboard Interior 42 Circuit Poles 240VAC 225A 3 Wire 14""

This is a NEW - unused Square D NQ42L2C14 Panelboard Interior 42 Circuit Poles 240VAC 225A 3 Wire 14"

Buyers and Re-sellers, don't miss this opportunity to purchase quality surplus equipment at a great price! There are many more surplus parts on our store, check it out!

Return Policy:

• Returns are accepted within 60 days of the delivery date. Rest assured we will cover all return shipping costs!
• All returns must be in "as shipped" original condition to qualify for a refund.
• Photos of packing and product is required for damaged items.
• Customer returns that satisfy all of the above requirements will be issued a refund including any applicable sales tax

Main

Panelboard Type	Main lugs
Branch Circuit Breaker Type	QOB QOB-VH QHB
Busbar Material	Copper

Complementary

Number of spaces	42
Enclosure Nominal Height	38 in (965.2 mm)
Enclosure Nominal Width	14 in (355.6 mm)
Enclosure Nominal Depth	5.75 in (146.05 mm) NEMA 1
Line Rated Current	225 A
[Iu] rated interrupted current	10 kA 22 kA 65 kA
Number of Phases	1 phase 3 wires
Voltage Rating	240 V AC 48 V DC
Tightening torque	40.005…50.007 lbf.in (4.52…5.65 N.m) 0.02…0.10 in² (13.30…67.43 mm²) (AWG 6...AWG 2/0) 100.01 lbf.in (11.3 N.m) 0.02…0.10 in² (13.30…67.43 mm²) (AWG 6...AWG 2/0) 274.99 lbf.in (31.07 N.m) 0.02…0.3 in² (13.30…177.3 mm²) (AWG 6...350 kcmil) 274.99 lbf.in (31.07 N.m) 0.02…0.2 in² (13.30…126.7 mm²) (AWG 6...250 kcmil) 274.99 lbf.in (31.07 N.m) 0.2…0.2 in² (107.2…152 mm²) (AWG 4...300 kcmil)
Height	58 in (1473.2 mm)
Width	8.63 in (219.20 mm)
Product Weight	19.831 lb(US) (8.995 kg)

Environment

Standards	UL CSA

Ordering and shipping details

Category	US1PE1A09151
Discount Schedule	PE1A
GTIN	785901327165
Returnability	Yes
Country of origin	MX
