Halo RSQ6089351EMWWB 6" Square Recesssed Downlight 800 Lumens

This is a NEW - unused Halo RSQ6089351EMWWB 6" Square Recesssed Downlight 800 Lumens

Buyers and Re-sellers, don't miss this opportunity to purchase quality surplus equipment at a great price! There are many more surplus parts on our store, check it out!

Return Policy:

• Returns are accepted within 60 days of the delivery date. Rest assured we will cover all return shipping costs!
• All returns must be in "as shipped" original condition to qualify for a refund.
• Photos of packing and product is required for damaged items.
• Customer returns that satisfy all of the above requirements will be issued a refund including any applicable sales tax

The RSQ6 is an integrated LED module / trim with a square shallow lens suitable for new construction, remodel and retrofit installation. Certified for use with Halo and compatible 6" housings and can be used with housings in direct contact with insulation. Integral gasket provides airtight compliance in non-airtight housings, provides code compliance and additional energy savings. Use for general area lighting in low to medium height ceilings where energy savings and long life are desired.

PRODUCT SPECIFICATIONS
MODULE

• Module / trim is field interchangeable and upgradable, LED module consists of LED array, optical assembly, driver and self-flanged trim
• Integral aluminum heat sink provides passive thermal cooling achieving L70 at 70,000 hours in IC and non-IC applications.

LED ARRAY

• Plurality of mid-power LEDs provide a uniform source with high efficiency and long life
• Available in 90 CRI minimum, R9 greater than 50 and color accuracy within 4 SDCM provides color accuracy and uniformity
• Available in 2700, 3000, 3500 and 4000 K fixed CCT
• Optional field selectable color temperature, select from 2700, 3000, 3500, 4000 and 5000 K CCT

OPTICAL ASSEMBLY

• Precision molded optic organizes source flux into wide distribution, useful for general area lighting
• Regressed flat lens provides uniformity
• Meets Energy Star color angular uniformity requirements, color deviation is less than 0.006 u' v

CONNECTORS

• Two-conductor wire mount CJT type connector is rated for 120V and mates with LED housings or E26 adapter (provided)

DRIVER

• Standard 1E constant current driver option with 120V 60 Hz input provides quiet operation
• Leading or trailing edge phase cut dimming to 5% with select controls, meets CA T24 flicker requirements

RETENTION

• Steel torsion springs hold module securely in the housing
• Rotates more or less 45 degree allowing trim to be aligned with architecture
• Module / trim can be removed from below the aperture for service or replacement
• Optional friction blades (provided) for installation in housings without torsion spring receivers

TRIM

• Die cast aluminum trim can be removed in the field and replaced with optional designer series trims to match many decors
• Step baffle provides additional cutoff to source
